Q.ik
Q.ik Sora
20"WHEEL FOLDING ELECTRIC BIKE
SPECIFICATIONS
The Sora is a compact 20”-wheel model that can be folded down in two movements thanks to two pivot points. The folding process is quick and easy and the bike’s compactness and lightweight build make it great for carrying on public transport or in the boot of a car.
The battery is integrated into the seat post and can be easily removed, transported and charged conveniently anywhere. The 5-level motor assistance is managed by a speed sensor.
Wheel size
20"x1,95”
Unfolded bike size
147x96x100 cms
Folded bike size
83x40x61 mm
Weight
21 Kg
Max. admissible load
100 Kg
Max Speed (motor assisted)
25Km
Motor placement
Rear engine
Sensor
Speed
Gear
7 speed external gear
Brakes
Front and rear 160mm disk. Mechanic
Battery
Seat post, removable
Battery charging time
3.5h
Display
Multifunction digital display. USB port
Assistance levels
5
Lighting
Front and rear lights from display.
Battery
36V 7Ah
Range
Till 40km
Fenders
Front and rear wheel aluminium fenders
Rear carrier admissible load
25Kg
Stem
Telescopic adjustable high stem
Color
Black / Dark blue / Dark green
Throttle lever
Optional
Anti-theft battery key locker
Optional
Motor
Shengy 36V 250W rear motor
Frame and forks
6061 aluminium alloy
Rims
Double wall aluminum alloy
Tire
Kenda 20" x 1.95" / 40 to 65 PSI
Battery
36V 7Ah
Chain wheel
Prowheel 48T
Free wheel
SHIMANO MF-TZ500-7
Rear derailleur
SHIMANO Tourney 7s
Shifter
MICROSHIFT 7S/P
Display
Naici KT-5 color LCD
Chain
KMC
Controller
Naici sine wave, speed sensor
FOLDED / UNFOLDED Q.ik Sora
ALUMINIUM ALLOY FRAME
The Sora is based on a lightand strong 6061 aluminium alloy frame. It has a tubular structure with a Z-shaped elliptical cross-section, with a cut-out and hinge in the middle. When unfolded, the bike is secured by a locking system that ensures a rigid and stable position for riding.
FOLDING SYSTEM
The Sora model folding system is intuitive, easy and fast.
The folding system involves two steps. The first step involves rotating the front part of the frame 180° to position the front wheel parallel to the rear wheel. The second step involves folding the handlebar post and handlebars to sit alongside the wheels. To stabilise the bike when it's folded, it is necessary to lower the seat post until it touches the ground and becomes the third point of support.
A two-piece magnets device located on the axles of the front and rear wheels fix the folded position of the bike. It prevents the parts from moving while being manipulated or rolling on the pavements.
7Ah REMOVABLE BATTERY
The Sora model is equipped with a 36V lithium battery with a 7Ah charge capacity, giving it a riding range of up to 40 km (according to the manufacturer). The battery fits neatly into the seat post, where the charging port and main power switch are also located. It can be easily removed, transported and charged anywhere without needing bike to be nearby.
The charging system features an innovative BMS, which prevents the battery from overcharging and overheating and regulates the release of energy for greater efficiency and longer use.
36V 250W MOTOR
The Seana features a 36V, 250W motor located in the rear wheel, which is has a factory-set power limitation to stop the bike from exceeding 25 km/h. By law, when the bike reaches this speed, the motor must stop providing assistance. The motor is powerful enough to meet the demands of overcoming steep slopes.
A pedalling pressure Torque type sensor controls the motor assistance depending on which of the five levels has been chosen.
It has a clutch system that allows the bike to roll without any resistance should the rider want to cycle without any help from the motor.
7-SPEED TRANSMISSION
The Sora's 7-speed transmission adjusts the pedalling effort without forcing the motor. The shift lever on the handlebars delivers accurate gear selection according to the gradient of the road. The derailleur is part of the Shimano 7-speed Tourney series.
160mm MECHANICAL DISK BRAKES
The Sora is equipped with 160 mm mechanical disc brakes on both the front and rear wheels. They offer great braking power and guarantee to stop the bike within a few metres in case of emergency in all riding conditions. In addition, squeezing the brakes automatically disables the motor, facilitating a more immediate brake response.
MAGNETIC BUCKLE
The Sora sets a magnetic device specifically designed to securely join the front fork and frame together when the bike is folded.
Q.ik Seana. Looking for a good value for money ebike?
Q.ik Sora is undoubtedly the ideal ebike for those who look for a full equipped and great quality 20' folding ebike for a more than reasonable price.
Disk brakes, Shimano 7 speed gear, metallic fenders, rear rack, telescopic stem, front and rear lights managed from display...
Sora will take you wherever you need to go with style and comfort. It's the ideal ebike for easy commuting and hassle-free storage.
